Ubiquiti UniFi Cloud Gateway Ultra UCG-ULTRA

Unleashed Performance

The Ubiquiti Cloud Gateway Ultra is a powerful and compact multi-WAN gateway designed to optimize your network performance and security. Whether you're managing a home network or a small business environment, this versatile device offers a comprehensive solution. Enjoy uninterrupted connectivity with automatic failover and load balancing across multiple internet connections. Experience smooth and secure network operations with 1 Gbps routing, integrated intrusion detection/prevention system (IDS/IPS), and advanced security features.

Centralized Control

The Cloud Gateway Ultra simplifies network management with its intuitive UniFi Network software interface. Run the entire UniFi Network application directly on the Cloud Gateway Ultra, eliminating the need for a dedicated controller. You can centrally manage over 30 UniFi Network devices and seamlessly connect with up to 300 clients for a scalable networking solution. Configure all your UniFi devices from a single platform and monitor network performance in real-time, gaining insights into traffic, bandwidth usage, and device health.

Compact and Versatile

The Cloud Gateway Ultra boasts a compact design that fits seamlessly into any environment. The integrated 0.96" LCM status display provides real-time information about network activity. The Cloud Gateway Ultra is powered by a USB-C connection, offering a flexible and reliable power solution (adapter included). With its robust features, user-friendly management, and compact design, the Ubiquiti Cloud Gateway Ultra is an ideal solution for those seeking a reliable and secure multi-WAN gateway for their home or small business network.

Technical Specifications

Mechanical

• Dimensions: 141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2")
• Weight: 520 g (1.1 lb)
• Enclosure material: Polycarbonate

Hardware

• Processor: Quad-core ARM® Cortex®-A53 at 1.5 GHz
• System memory: 3 GB DDR4
• On-board storage: 16 GB eMMC
• Management interface: Ethernet, Bluetooth
• Networking interface:
  • LAN: (4) GbE RJ45 ports
  • WAN: (1) 1/2.5 GbE RJ45 port
• IDS/IPS throughput: 1 Gbps
• Power method: USB type C (5V DC/3A)
• Supported voltage range: 100–240V AC
• Max. power consumption: 6.2W
• LCM display: 0.96" status display
• Button: Factory reset
• Operating temperature: -10 to 40° C (14 to 104° F)
• Operating humidity: 5 to 95% noncondensing
• Certifications: CE, FCC, IC

Gateway Features

• Performance: Redundant WAN with failover and load balancing
• WiFi QoS with UniFi APs
• Application, domain, and country-based QoS
• Application and device type identification
• Additional internet failover with LTE Backup
• **Internet quality and outage reporting

Next-generation security

• Application-aware firewall rules
• Signature-based IPS/IDS threat detection
• Content, country, domain, and ad filtering
• VLAN/subnet-based traffic segmentation
• **Full stateful firewall

Advanced networking

• License-free SD-WAN
• WireGuard, L2TP and OpenVPN server
• OpenVPN client
• OpenVPN and IPsec site-to-site VPN
• One-click Teleport and Identity VPN
• Policy-based WAN and VPN routing
• DHCP relay
• Customizable DHCP server
• IGMP proxy
• **IPv6 ISP support

LEDs

• Ethernet: Green: link/activity

Application Requirements

• Mobile app: UniFi iOS™: Version 10.12.0 and later
• UniFi Android™: Version 10.11.2 and later
