Product code: A42G-HbeP
Architecture: ARM 32bit
CPU: AN7563PT
CPU core count: 2
CPU nominal frequency: 950 MHz
CPU Threads count: 2
Switch chip model: AN7563PT
RouterOS license: 4
Operating System: RouterOS v7
Size of RAM: 512 MB
Storage size: 128 MB
Storage type: NAND
MTBF: Approximately 100'000 hours at 25C
Tested ambient temperature: -40°C to 50°C
Wireless 2.4 GHz Max data rate: 688 Mbit/s
Wireless 2.4 GHz Number of chains: 2
Wireless 2.4 GHz standards: 802.11b/g/n/ax/be
Antenna gain dBi for 2.4 GHz: 4.4
Wireless 2.4 GHz chip model: MT7991
Wireless 2.4 GHz generation: Wi-Fi 7
Wireless 5 GHz Max data rate: 2882 Mbit/s
Wireless 5 GHz Number of chains: 3
Wireless 5 GHz standards: 802.11a/n/ac/ax/be
Antenna gain dBi for 5 GHz: 7
Wireless 5 GHz chip model: MT7991
Wireless 5 GHz generation: Wi-Fi 7
WiFi speed: BE3600
10/100/1000 Ethernet ports: 3
Number of 2.5G Ethernet ports: 1
Number of DC inputs: 1 (USB-C)
Max power consumption: 12 W
Cooling type: Passive
USB C input Voltage: 5 V
Certification: CE, FCC, IC, EAC, ROHS
IP: 20
CPU temperature monitor: Yes
Included parts: 5 V 2.4 A power adapter (black)
Note: The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase.
2.4 GHz 1MBit/s: Transmit 26.5 dBm, Receive Sensitivity -100
2.4 GHz 11MBit/s: Transmit 25.5 dBm, Receive Sensitivity -94
2.4 GHz 6MBit/s: Transmit 25.5 dBm, Receive Sensitivity -96
2.4 GHz 54MBit/s: Transmit 23.5 dBm, Receive Sensitivity -80
2.4 GHz MCS0: Transmit 24 dBm, Receive Sensitivity -96
2.4 GHz MCS7: Transmit 22 dBm, Receive Sensitivity -75
2.4 GHz MCS9: Transmit 20.5 dBm, Receive Sensitivity -70
2.4 GHz MCS11: Transmit 20.5 dBm, Receive Sensitivity -67
2.4 GHz MCS13: Transmit 19.5 dBm, Receive Sensitivity -65
5 GHz 6MBit/s: Transmit 26 dBm, Receive Sensitivity -96
5 GHz 54MBit/s: Transmit 23 dBm, Receive Sensitivity -81
5 GHz MCS0: Transmit 24 dBm, Receive Sensitivity -96
5 GHz MCS7: Transmit 23 dBm, Receive Sensitivity -77
5 GHz MCS9: Transmit 22 dBm, Receive Sensitivity -72
5 GHz MCS11: Transmit 21 dBm, Receive Sensitivity -69
5 GHz MCS13: Transmit 20 dBm, Receive Sensitivity -67
