Ubiquiti Networks designed airMAX ac radios for high performance and ease of installation. You have the freedom to deploy the Bullet AC anywhere in the world, as it allows for a high degree of flexibility in configuring channel bandwidths.
airOS software
airOS 8 is the revolutionary operating system for Ubiquiti airMAX ac products.
Throughput Breakthrough airMAX ac supports high data rates, which require dense modulation:
256QAM – a significant increase from
64QAM, which is used in airMAX.
With their use of proprietary airMAX ac technology, airMAX ac products supports up to 500+ Mbps (maximum 80 MHz channel width) real TCP/IP throughput – up to triple
the throughput of standard airMAX products.
Dual-Band Frequency The Bullet AC covers both 2.4 and 5 GHz radio bands, covering a wide range of frequencies that work well for both short and long‑distance links.
Throughput: 2.4 GHz - 160+ Mbps; 5 GHz - 300+ Mbps
Max. power consumption: ~ 8W
Power Supply: 24VDC, 0.3A
Power supply: 24V Passive PoE (Pairs 4, 5+; 7, 8 Return)
