Access Point Ubiquiti NanoBeam M5
The NanoBeam® mounts to a variety of surfaces including poles or walls, and offers the freedom of three-axis alignment. No screws are required for pole-mounting, and only a single wall screw (not included) is required for wall-mounting.
The form factor of the NanoBeam® features the highest gain for its size. The NanoBeam’s excellent beam directivity provides the best performance in high-noise environments.
Ubiquiti’s airMAX® technology is proven in millions of deployments worldwide, exhibiting outstanding performance in outdoor environments.
The TDMA airMAX protocol enables unprecedented scalability, high throughput and low latency in unlicensed, multipoint networks.
Use the optional NBE-WMK Wall Mount Kit for enhanced stability when mounting the NanoBeam on a wall.
Features:
- CPU: Atheros MIPS 74Kc, 560 MHz / 64 MB DDR2, 8 MB Flash
- 1x Ethernet ports: 10/100 M
- Max. VSWR: 1.5:1
- airOS, airView, airControl,
- Wind Survivability: 200 km/h (125 mph)
- Маx. comsumption: 8W
- Power supply: 24V, 0.5A PoE
- Polarization: Dual linear
- ESD/EMP protection: air: ± 24 kV, contact: ± 24 kV
