LoRa access point MikroTik wAP LR9 kit RBwAPR-2nD&R11e-LR9G

The wAP LR9G kit is a rugged, out-of-the-box LoRa® gateway built into MikroTik’s proven wAP form factor. It is ideal for outdoor deployments like smart agriculture, industrial monitoring, or any LoRa® IoT setup requiring durability and reliable performance.

Key Features:

• LoRa® 915 MHz support

• Built-in GPS (MT3337V)

• High sensitivity: up to -141 dBm

• 2.4 GHz Wi-Fi (802.11b/g/n dual-chain)

• 3 power input options: Passive PoE, DC jack (9–28 V), Automotive (12–30 V)

• SMA female connectors for external antennas

• Compatible with public and private LoRa® networks (e.g., The Things Network)

• Preinstalled UDP packet forwarder

• IP54-rated weather-resistant case

Note: The device does not include an LTE modem. The SIM slot can only be used if the LoRa card is removed and replaced with an LTE modem.

Specifications

General

• Product code: RBwAPR-2nD&R11e-LR9G

• Architecture: MIPSBE

• CPU: QCA9531, 1 core @ 650 MHz

• RAM: 64 MB

• Storage: 16 MB FLASH

• Operating system: RouterOS v7 (License level 4)

• MTBF: ~200,000 hours at 25°C

• Operating temperature: -40°C to +60°C

• Suggested price: $149.00

Powering

• Power inputs: 3 (PoE-IN, Automotive, DC jack)

• PoE input: Passive PoE, 9–28 V

• DC jack input: 9–28 V

• Automotive input: 12–30 V

• Max power consumption: 7 W

• Cooling: Passive

Wireless (2.4 GHz)

• Max data rate: 300 Mbps

• Standards: 802.11b/g/n (Wi-Fi 4)

• Chains: 2

• Chipset: QCA9531

• Antenna gain: 2 dBi

Wireless TX/RX Power

• 1 Mbit/s: TX 22 dBm / RX -96 dBm

• 11 Mbit/s: TX 22 dBm / RX -89 dBm

• 6 Mbit/s: TX 20 dBm / RX -93 dBm

• 54 Mbit/s: TX 18 dBm / RX -74 dBm

• MCS0: TX 20 dBm / RX -93 dBm

• MCS7: TX 16 dBm / RX -71 dBm

Ethernet

• 1x 10/100 Mbps Ethernet port

Peripherals

• 1x miniPCIe slot

• 1x Mini SIM slot (usable with LTE modem only)

• GPS connector: uUFL

Monitoring

• Voltage monitor: Yes

• PCB temperature monitor: Yes

Certifications

• FCC, IC, EAC

• IP rating: IP54

Included Accessories

• 24V 0.8A power adapter

• Gigabit PoE injector

• K-52 fastening set

• wAP desktop stand

• Ceiling mount bracket

• Metal ring
