Switch Ubiquiti US8-150W 8Port

Technical Specifications

Dimensions    235 x 43 x 204 mm (9.3 x 1.7 x 8")
Weight    1.7 kg (3.7 lb)
Enclosure material    SGCC steel
Hardware
Management interface    Ethernet In-Band
Networking interface    (8) GbE RJ45 ports
(2) 1G SFP ports
PoE interface    (8) PoE/PoE+ (Pins 1, 2+; 3, 6-)
24V DC passive PoE (Pins 4, 5+; 7, 8-)
Total non-blocking throughput    10 Gbps
Switching capacity    20 Gbps
Forwarding rate    14.88 Mpps
Power method    Universal input, 100—240V AC, 50/60 Hz
Power supply    AC/DC, internal, 150W
Max. power consumption    Excluding PoE output: 20W
Including PoE output: 150W
Total available PoE    130W
Max. PoE wattage per port by PSE    PoE: 17W
PoE+: 34W
Voltage range PoE mode    24V passive PoE: 20–27V
PoE+: 50—57V
ESD/EMP protection    Air: ± 24kV, contact: ± 24kV
Operating temperature    -5 to 45° C (23 to 113° F)
Operating humidity    5 to 95% noncondensing
Certifications    CE, FCC, IC
LEDs
Ethernet    PoE
Link/Speed/Activity
SFP    Link/Speed/Activity
