Ubiquiti UniFi Ultra (42W)
Overview
Dimensions
203 x 76 x 33 mm (8 x 3 x 1.3")
Port Layout
1 GbE RJ45
8 (7 PoE+; 1 PoE++ input)
Max. PoE Output
Up to PoE+
Total PoE Availability
PoE++ input: 42W PoE+ input: 16W 60W PoE adapter input: 42W 60W AC adapter input: 52W 210W AC adapter input: 202
Form Factor
Compact desktop, wall, magnetic
Performance
Switching Capacity
16 Gbps
Total Non-Blocking Throughput
8 Gbps
Forwarding Rate
12 Mpps
Supported VLANs
256
MAC Address Table Size
4,000
Layer 2 Features
STP & RSTP
Yes
Egress Rate Limit
Yes
Flow Control
Yes
Storm Control
Yes
Multicast & Broadcast Rate Limiting
Yes
Port Isolation
Yes
Port Mirroring
Yes
Jumbo Frames
Yes
Loop Protection
Yes
Hardware
PoE Ports
PoE+
7
PoE++
1
Max. PoE Wattage per Port by PSE
PoE+
30W
Max. Power Consumption
9W (Excluding PoE Output) with PoE input 8W (Excluding PoE Output) with adapter input 210W (Including PoE Output) with 210W AC adapter input
Power Method
(1) AC/DC adapter (Excluded) (1) PoE++
Power Input Method
DC Input PoE
Supported Voltage Range
50—57V DC/PoE
Management
Ethernet
Heat Dissipation (Excluding PoE Output)
30.708 BTU/hr 27.296 BTU/hr
Weight
Device: 320 g (11.3 oz) Wall mount: 45 g (1.6 oz)
Enclosure Material
Polycarbonate
Ambient Operating Temperature
PoE++ input: -30 to 60° C (-22 to 140° F) 60W AC adapter input: -20 to 45° C (-4 to 113° F) 210W AC adapter input: -20 to 60° C (-4 to 140° F)
Ambient Operating Humidity
10 to 90% noncondensing
Certifications
CE, FCC, IC
