Ubiquiti EdgeSwitch ES-48-750W 48 port

ES-48-750W_VZ
Out of stock
  • EAN 810354022289
  • Приложение Rackmount
  • Тип ManagedEdge Switch
  • Brand UBIQUITI
full product features
Price
2 163,84 BGN
Add to wishlist Comparison list

Ubiquiti EdgeSwitch ES-48-750W 48 port

Build and expand your network with Ubiquiti Networks® EdgeSwitch™, part of the EdgeMAX® line of products.
The EdgeSwitch is a fully managed, PoE+ Gigabit switch, delivering robust performance and intelligent switching for growing networks.
The EdgeSwitch offers an extensive suite of advanced Layer-2 switching features and protocols, and also provides Layer-3 routing capability.

Powerful Enterprise Switch Models
The EdgeSwitch™ delivers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.
Total non-blocking throughput: up to 26 Gbps for 24-port models and up to 70 Gbps for 48-port models.

Enterprise-Class Features
The EdgeSwitch™ supports an extensive suite of advanced Layer-2 switching features and protocols, and also provides Layer-3 routing capability.

Optical Fiber Backhaul
Two SFP ports support uplinks of up to 1 Gbps. For high-capacity uplinks, each 48-port model includes two SFP+ ports for uplinks of up to 10 Gbps.

Convenient PoE+ Support
The EdgeSwitch™ features auto-sensing IEEE 802.3af/at and 24V passive PoE to power multiple devices on the network.

Advanced UI
The comprehensive UI is easy to learn and allows administrators to configure and monitor features in a graphical user interface. For advanced users, a Command-Line Interface (CLI) is available through telnet and SSH.

Features:

  • 48 Gigabit RJ45 Ports
  • 2 SFP+ Ports
  • 2 SFP Ports
  • 1 Serial Console Port
  • Non-Blocking Throughput: 70 Gbps
  • Switching Capacity: 140 Gbps
  • Forwarding Rate: 104.16 Mpps
  • Maximum Power Consumption: 750W
  • Supports POE+ IEEE 802.3at/af and 24V Passive PoE
  • Rackmountable
Availability:
No stock
Brand:
UBIQUITI
Warranty:
24 месеца

Мрежови продукти - Суичова

EAN:
810354022289
Ethernet портове:
  • 140 Gbps
L3 Switching Features:
  • Static Routing
Quality of Service:
  • Access Control Lists (ACLs), Permit/Deny Actions for Inbound IP and Layer 2 Traffic Classification
  • Class of Service (CoS) Queue Mapping Configuration
  • Differentiated Services (DiffServ)
  • Optional ACL Rule Attributes
Вид на монтаж:
  • 1U 19-inch rack-mountable steel case
  • Rackmount
Експлоатационни качества:
  • Packet Forwarding Rate 104.16Mpps
Захранване:
  • 100~240VAC, 50/60Hz
Интерфейс:
  • 1 Console Port
  • 2 SFP ports
  • 2 SFP+ ports
  • 48 10/100/1000Mbps RJ45 Ports
Охлаждане:
  • Пасивно
Приложение:
  • Rackmount
Работна влажност:
  • 5%~90% без кондензация
Работна температура:
  • -5 to 40° C (23 to 104° F)
Размери височина:
43.7 mm
Размери дълбочина:
374.6 mm
Размери ширина:
485.04 mm
Сертификати:
  • CE
  • FCC
  • IC
Сигурност:
  • ESD/EMP Protection Air: ±24 kV, Contact: ±24 kV
  • IEEE 802.1AB: Link Layer Discovery Protocol (LLDP)
  • IEEE 802.1X Port/MAC Based authentication, Radius,Guest VLAN
Системни изисквания:
  • Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7, MAC® OS, NetWare®, UNIX® or Linux.
Софтуерни функции:
  • ANSI/TIA-1057: LLDP-Media Endpoint Discovery (MED)
  • IEEE 802.1ak: Virtual Bridged Local Area Networks - Amendment 07: Multiple Registration Protoco
  • IEEE 802.1D-2004: Dynamic L2 multicast registration: Clause 10 (GMRP)
  • IEEE 802.1D-2004: Generic Attribute Registration Protocol: Clause 12 (GARP)
  • IEEE 802.1D: Spanning Tree Compatibility
  • IEEE 802.1p: Ethernet Priority with User Provisioning and Mapping
  • IEEE 802.1Q-2003: Dynamic VLAN registration: Clause 11.2 (GVRP)
  • IEEE 802.1Q: Virtual LANs with Port-Based VLANs
  • IEEE 802.1S: Multiple Spanning Tree Compatibility
  • IEEE 802.1X: Port-Based Authentication with Guest VLAN Support
  • IEEE 802.3ac: VLAN Tagging
  • IEEE 802.3ad: Link Aggregation
  • IEEE 802.3x: Flow Control
  • RFC 4541: Considerations for Internet Group Management Protocol (IGMP) Snooping Switches
  • • IEEE 802.1W: Rapid Spanning Tree Compatibility
Съвместимост с мрежови стандарти:
  • IEEE 802.1d
  • IEEE 802.1p
  • IEEE 802.1q
  • IEEE 802.1w
  • IEEE 802.1x
  • IEEE 802.3ab
  • IEEE 802.3u
Тип:
  • Edge Switch
  • Managed
Управление/Management:
  • Autoinstall Support for Firmware Images and Configuration Files
  • Industry-Standard CLI
  • Password Management
  • Secure Copy (SCP)
  • SNMP v1, v2, and v3
  • SSH 1.5 and 2.0
  • SSL 3.0 and TLS 1.0
  • Telnet (Multi-Session Support)
  • Web UI

Брошура (EdgeSwitch_DS.pdf, 5,039 Kb) [Download]
