Ubiquiti PoE++ Adapter
Specifications
- Model: U-PoE++
- Dimensions: 106 x 63 x 34 mm (4.2 x 2.5 x 1.3")
- Weight: 210 g (7.4 oz)
- Output Voltage: 48V DC @ 1.25A
- LAN Activity Indicator: No
- Gigabit LAN Port: Yes
- Remote Reset Capability: No
- Reset Button: No
- Rated Voltage: 100—240V AC @ 50/60Hz
- Input Current:
- 1.3A @ 120V AC
- 0.75A @ 230V AC
- Inrush Current:
- <100A peak @ 120V AC
- <200A peak @ 230V AC
- Efficiency: 85+%
- Output Ripple: 1% max.
- Switching Frequency: 65 kHz
- Line Regulation: ≤ 1%
- Load Regulation: ≤ 3%
- 2-Pair Powering: No
- 4-Pair Powering: Pins 1, 2, 4, 5 (+) and 3, 6, 7, 8 (-)
- AC Connector: IEC-320 C6
- Data In / PoE: RJ45 shielded socket
- Surge Protection: Differential and common mode
- Clamping Protection: 11V data, 60V power
- Max. Surge Discharge: 1500A (8/20 μs) power
- Peak Pulse Current: 36A (10/1000 μs) data
- Shunt Capacitance: <5 pF data
- Response Time: <1 ns
- Power Method: Universal AC input, 100—240V AC, 50/60 Hz
- Power Supply: AC/DC
- Supported Voltage Range: 100—240V AC
- Max. PoE+ Wattage per Port by PSE: 60W
- Ambient Operating Temperature: 0 to 40° C (32 to 104° F)
- Storage Temperature: -30 to 70°C (-22 to 158° F)
- Ambient Operating Humidity: 10 to 95% non-condensing
- Certifications: CE, FCC, IC, UL, UKCA, KC, CCC, KC, RoHS
