8-port managed gigabit switch Ubiqtui UniFi Switch 8 US-8
Build and expand your network with Ubiquiti Networks UniFi Switch, part of the UniFi line of products.
The 8-port models feature Gigabit Ethernet ports in a compact form factor.
The switches are fully manageable, delivering robust performance and intelligent switching for your growing networks.
The UniFi Switch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.
For its total, non-blocking throughput, each supports up to 8 Gbps with a switching capacity of 16 Gbps.
Features:
- 8x Gigabit RJ45 Ports
- Non-Blocking Throughput: 8 Gbps
- Switching Capacity: 16 Gbps
- Forwarding Rate: 11.9 Mpps
- Maximum Power Consumption: 12W
- Power Method: 48VDC, Max. 2A
- ESD/EMP Protection: Air: ± 24 kV, Contact: ± 24 kV
- Max. Passive PoE Wattage per Port:
- PoE Mode 1: 12W @ 802.3at
- PoE Mode 2: 12W @ 48V
- DC Input Mode: 12W @ 48V
- PoE In Interface (Port 1): PoE Mode 1: 802.3af/at (Pins +1, 2; -3, 6)
- PoE Mode 2: 48V (2-Pair Pins +4, 5; -7, 8)
- PoE Out Interface (Port 8) PoE Mode 1: 48V (Pins +1, 2; -3, 6)
- PoE Mode 2: Passive 48V
- (2-Pair Pins +4, 5; -7, 8)
- DC Input Mode: DC Passthrough
- (Pins +1, 2; -3, 6)
- Management Interface: Ethernet In-Band Management
