48-ports managed PoE switch Ubiquiti UniFi Switch USW-48-POE

USW-48-POE_VZ
Out of stock
full product features
Price
1 545,60 BGN
Add to wishlist Comparison list

48-ports managed PoE switch Ubiquiti UniFi Switch USW-48-POE

The USW-48-PoE is a configurable Gigabit Layer 2 switch with 48 Gigabit Ethernet ports including 32 auto-sensing 802.3at PoE+ ports, and 4 SFP ports. It provides Gigabit PoE links to your RJ45 Ethernet devices and Gigabit fiber uplink options to your enterprise network.
The USW-48-PoE features a 1.3" touch LCM to provide status.
Managed and configured by the UniFi Network Controller with UniFi mobile app support, the USW-48-PoE offers an extensive suite of advanced Layer 2 switching protocols and features, including operation mode (switching, mirroring, or aggregate) per port.
The UniFi Network Controller and mobile app allow admins to configure and monitor virtually all of the switch features in a graphical user interface from anywhere.

Features:

  • 48x Gigabit Ethernet Ports including (32) 802.3at PoE+
  • 4x 1G SFP Ports
  • 1.3" touch LCM
  • Managed by UniFi Controller
  • 240W Power supply
  • Power Method: 100-240VAC, 50/60 Hz, Universal Input
  • Power Supply: AC/DC, Internal, 240W
  • Supported Voltage Range: 100 to 240VAC
  • Max. Power Consumption (Excluding PoE Output): 45W

PoE

  • PoE Interfaces Ports 1-32: POE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
  • Max. PoE Wattage per Port by PSE 802.3at: 32W
  • Voltage Range 802.3af Mode: 44-57V
  • Voltage Range 802.3at Mode: 50-57V
Availability:
No stock
Brand:
UBIQUITI
Warranty:
24 месеца

Мрежови продукти - Суичова

EAN:
0810010072146
Вид на монтаж:
  • 1U rackmount case
  • Rackmount
Експлоатационни качества:
  • Forwarding Rate 77.4Mpps
Захранване:
  • 100~240VAC, 50/60Hz
  • 240W вградено захранване
  • Max. Power consumption 45W
Интерфейс:
  • 4 SFP Ports
  • 48 10/100/1000Mbps RJ45 Ports
Мрежови характеристики:
  • Auto-MDI/MDIX Ports
  • Switching Capacity: 104 Gbps
Охлаждане:
  • Активно
Приложение:
  • Rackmount
Работна влажност:
  • 10%~90% без кондензация
Работна температура:
  • -5 to 40° C (23 to 104° F)
Размери височина:
43.7 mm
Размери дълбочина:
285.6 mm
Размери ширина:
443 mm
Сертификати:
  • CE
  • FCC
  • IC
Сигурност:
  • 802.1x and Radius Authentication
  • ESD/EMP Protection: Air: ± 16 kV, Contact: ± 12 kV
Софтуерни функции:
  • UniFi OS
Съвместимост с мрежови стандарти:
  • 802.3 af
  • IEEE 802.3 at
Тегло, кг.:
4.61 кг.
Тип:
  • Managed
  • UniFi Switch
Управление/Management:
  • Web UI

Брошура (usw_poe_ds, 6,154 Kb) [Download]
